Type Mobile Cone Crushing Plant
Crawler

It integrates mechanical, hydraulic, electrical, automation, and other technologies, and it has many advantages such as high crushing efficiency, low production cost, convenient maintenance and adjustment, and excellent crushing product size. It is mainly used in secondary and tertiary crushing in metal mines and construction sand and stone processing. It is not afraid of narrow terrain and harsh environments, and it is the latest generation of products in the mining construction industry and metal mining industry.

TECHNICAL DATA

Crawler type mobile cone crushing plant		CP200 crawler type mobile cone crushing plant			CP300 crawler type mobile cone crushing plant			CP400 crawler type mobile cone crushing plant
Model		Items and specifications	power (kw)	Quantity(set)	Items and specifications	Power (kw)	Quantity(set)	Items and specifications	Power (kw)	Quantity(set)
Crushing equipment	Equipment Model	CP200	/	1	CP300	/	1	CP400	/	1
	Triangle belt	Standard	/	1	25N-5100	/	7	Standard	/
	Motor	Standard	160	1	Y355M2-4	220	1	Standard	315	1
Return screen	Equipment	1536	/	1	1542	/	1	1542	/	1
Return screen	Vibration motor	Standard	3.06	2	Standard	3.7	2	Standard	3.06	2
Frame	Hydraulic crawler chassis	Standard	/	1	Standard	/	1	Standard	/	1
Frame	Boat frame		/	1	plate thickness=12-20mm	/	1		/	1
Upper sieve conveyor	Specification	B1000*6m	7.5	1	B1000*6m	7.5	1	B1200*6.5m	7.5	1
Upper sieve conveyor	Drive method	Electric drum drive	/	1	Electric drum drive	/	1	Electric drum drive	/	1
Main conveyor	Specification	B1000*9m	11	1	B1000*10.5m	11	1	B1200*10m	11	1
Main conveyor	Drive method	Electric drum drive	/	1	Electric drum drive	/	1	Electric drum drive	/	1
Under the screen conveyor	Specification	B1000*6m	7.5	1	B1200*6.2m	7.5	1	B1200*6.2m	7.5	1
Under the screen conveyor	Drive method	Electric drum drive	/	1	Electric drum drive	/	1	Electric drum drive	/	1
Transfer conveyor	Specification	B650*2m	3	1	B650*2m	3	1	B650*2m	3	1
Transfer conveyor	Drive method	Electric drum drive	/	1	Electric drum drive	/	1	Electric drum drive	/	1
Return conveyor	Specification	B500*9m	5.5	1	B500*11m	5.5	1	B500*11m	7.5	1
Return conveyor	Drive method	Electric drum drive	/	1	Electric drum drive	/	1	Electric drum drive	/	1
Single power system	Walking engine	Yuchai diesel engine	106	1	Yuchai diesel engine	80	1	Yuchai diesel engine	145	1
Dual power system	Generator set	Yuchai diesel engine	300	1	Yuchai diesel engine	400	1
Electrical System	Electric control cabinet	Host soft-start, CHINT electrical components.	/	1	Host soft-start, CHINT electrical components.	/	1	Host soft-start	/	1
Matching		Belt Conveyor Folding Cylinder		1	Belt Conveyor Folding Cylinder		1	Belt Conveyor Folding Cylinder		1
Matching		Hydraulic pumps, valves, stations and tubing accessories		1	Hydraulic pumps, valves, stations and tubing accessories		1	Hydraulic pumps, valves, stations and tubing accessories		1
Dimensions(m)L×W×H		Working size174.84.1	Transport size173.33.6		Working size18.545.1	Transport size19.83.64		Working size19.55.14.9	Transport size19.53.73.9
Weight (t)		Single-power model:≈45t,Dual-power models:≈47t			Single-power model:≈55t,Dual-power models:≈57t			≈65t
Power (kw)		Single-power model: 200.62kw(not including walking engine power),Dual-power models: 200.32kw(not including generator set power)			Single-power model: 264.1kw(not including walking engine power),Dual-power models: 264.1kw(not including generator set power)			357.62kw(not including generator set power)

*Details may vary based on application
**Weight inclusive of motor & accessories.
Note:All the above technical details may vary at any time during engineering process & design development.
