Type Mobile Screening Plant
Crawler
Vanguard Machinery crawler-type mobile jaw crusher plant is suitable for all-natural stones coarse crushing. It adopts crawler-type vehicle chassis, fully hydraulic drive, equipped with large reduction ratio jaw crusher, feeder, belt conveyor, and other auxiliary equipment, forming an integrated group operation mode, a one-stop solution to the problem of materials coarse crushing. Vanguard Machinery crawler-type mobile crushing plant has high reliability and adaptability, whether narrow terrain and harsh environments, and are widely used in road and bridge construction, urban construction, metallurgy, energy, and other fields.
WATCH VIDEO
TECHNICAL DATA
Crawler-type mobile screening and crushing plant | 2YA1860 crawler-type mobile screening and crushing plant | 2YA2160 crawler-type mobile screening and crushing plant | 3YA1860 crawler-type mobile screening and crushing plant | 3YA2160 crawler-type mobile screening and crushing plant | |||||||||
Model | Items and specifications | power (kw) | Quantity(set) | Items and specifications | Power (kw) | Quantity(set) |
Items and specifications |
Power (kw) |
Quantity(set) |
Items and specifications | Power (kw) | Quantity(set) | |
Vibrating Screen | Equipment | 2YA1860 | / | 1 |
2YA2160 |
/ | 1 |
3YA1860 |
/ |
1 |
3YA2160 | / | 1 |
Motor | 4 |
22 |
1 | 4 |
30 |
|
4 |
22 |
1 |
Y200L-4 |
30 |
|
|
Frame | Hydraulic crawler chassis | Standard | / |
1 |
Standard | / |
|
Standard |
/ |
|
Standard | / |
|
Boat frame | plate thickness=12-20mm | / | 1 | plate thickness=12-20mm | / | 1 | plate thickness=12-20mm |
/ |
1 |
plate thickness=12-20mm |
/ |
1 | |
Main conveyor | Specification | B800*11.5m |
75 |
1 |
B1200*11.5m | 11 | 1 |
B800*11.5m |
7.5 |
|
B1200*11.5m | 11 | 1 |
Drive method | Electric drum drive |
/ |
1 |
Electric drum drive | / | 1 |
Electric drum drive |
/ |
|
Electric drum drive | / | 1 | |
Large material conveyor | Specification | B650*7m |
5.5 |
1 | B650*7m |
5.5 |
1 |
B650*7m |
5.5 |
1 |
B650*7m |
5.5 |
1 |
Drive method | Electric drum drive | / | 1 | Electric drum drive | / | 1 |
Electric drum drive |
/ |
1 |
Electric drum drive | / | 1 | |
Medium material conveyor |
Specification | B650*9.5m |
5.5 |
1 | B650*9.5m | 5.5 | 1 |
B650*9.5m |
5.5 |
1 |
B650*9.5m | 5.5 | 1 |
Drive method | Electric drum drive | / | 1 | Electric drum drive | / | 1 |
Electric drum drive |
/ |
1 |
Electric drum drive | / | 1 | |
Under the screen conveyor | Specification | B800*8.5m | 7.5 | 1 | B1000*8.5m | 7.5 | 1 |
B800*8.5m |
7.5 |
1 |
B1000*8.5m | 7.5 | 1 |
Drive method | Electric drum drive | / | 1 | Electric drum drive | / | 1 |
Electric drum drive |
/ |
1 |
Electric drum drive | / | 1 | |
Medium and fine material conveyor |
Specification | / | / | / | / | / | / |
B650*9.5m |
5.5 |
1 |
B650*9.5m |
5.5 |
1 |
Drive method | / | / | / | / | / | / |
Electric drum drive |
/ |
1 |
Electric drum drive |
/ |
1 |
|
Single power system | Walking engine | Yuchai diesel engine |
80 |
1 | Yuchai diesel engine |
80 |
1 |
Yuchai diesel engine |
80 |
1 |
Yuchai diesel engine | 80 | 1 |
Dual power system | Generator set | Yuchai diesel engine | 120 | 1 | Yuchai diesel engine | 120 | 1 |
Yuchai diesel engine |
120 |
1 |
Yuchai diesel engine | 120 | 1 |
Electrical System | Electric control cabinet | Host soft-start, CHINT electrical components. | / | 1 | Host soft-start, CHINT electrical components. | / | 1 |
Host soft-start, CHINT electrical components. |
/ |
1 |
Host soft-start, CHINT electrical components. | / | 1 |
Matching | Belt Conveyor Folding Cylinder | 1 | Belt Conveyor Folding Cylinder | 1 |
Belt Conveyor Folding Cylinder |
1 |
Belt Conveyor Folding Cylinder | 1 | |||||
Hydraulic pumps, valves, stations and tubing accessories | 1 | Hydraulic pumps, valves, stations and tubing accessories | 1 |
Hydraulic pumps, valves, stations and tubing accessories |
1 |
Hydraulic pumps, valves, stations and tubing accessories | 1 | ||||||
Dimensions(m)L×W×H | Working size15.3*17*5.8 | Transport size18*4*3.9 | Working size15.3*17.2*6 | Transport size18*4.1*4.1 |
Working size:15.3*17*6 |
Transport size18*4*4.1 |
Working size15*17.2*6 | Transport size18*4.1*4.1 | |||||
Weight (t) | Single-power model30tDual-power models31t | Single-power model32tDual-power models33t |
Single-power mode:30t Dual-power models:31t |
Single-power model33t Dual-power models34t | |||||||||
Power (kw) | Single-power model: 48kw(not including walking engine power),Dual-power models: 48kw(not including generator set power) | Single-power model: 59.5kw(not including walking engine power),Dual-power models: 59.5kw(not including generator set power) |
Single-power model53.5kw (not including walking engine power) Dual-power models53.5kw (not including generator set power) |
Single-power model 65kw (not including walking engine power) Dual-power models65kw (not including generator set power) |
*Details may vary based on application
**Weight inclusive of motor & accessories.
Note:All the above technical details may vary at any time during engineering process & design development.
