HOME / PRODUCTS / SAND MAKING MACHINE / Series Sand Washer

Series Sand Washer
LSX

LSX Series Sand Washing Machine has two kinds of single-spin and double-spin, with high cleanliness, reasonable structure, large capacity, low power consumption, sand loss in the process of sand washing, especially the drive parts of sand washing machine are separated from water and sand, so its failure rate is much lower than the commonly used sand washing machine, is the best choice for upgrading the sand washing industry.

WATCH VIDEO

TECHNICAL DATA

Model	Diameter (mm)	Length (mm)	Feed size (mm)	Capacity (t/h)	Speed (r/min)	Power (kW)	Water (t/h)	Outer Dimension (mm)	Weight (t)
LSX920	915	7585	≤10	100	21	11	10-80	842028103960	6.3
2LSX920	915	7585	≤10	200	21	11*2	20-160	842037653960	11.1
LSX1120	1115	9782	≤10	175	17	15	20-150	1097039454720	10.2
2LSX1120	1115	9782	≤10	350	17	15*2	40-300	1097052504720	17.9

*Details may vary based on application
**Weight inclusive of motor & accessories.
Note:All the above technical details may vary at any time during engineering process & design development.
