Series Fine Sand Recycling Machine
WS

The fine sand recovery device overcomes the difficult problem that the sand is washed and dehydrated by sand washing machine in traditional technology and the loss of fine sand is difficult to control.

WATCH VIDEO

TECHNICAL DATA

Model	Separator specification	Size of dewatering screen	Dehydration Screen Power（KW）	Type of pump	Pump power（KW）	processing capacity（T）	Shape size	Remarks
WS8018	250	800*1800	0.75*2	2/3	11	5--10	220014002150	①The pump can be selected according to the amount of water on site. ②2/3 pump flow rate 45 tons / hour ③3/4 pump flow 80-100 tons / hour ④4/6 pump flow 300-360 tons / hour ⑤The pump can be selected according to the amount of water on site.
WS9020	300	900*2000	1.1*2	3/4	15	10--20	250014002300
WS1225	350	1200*2500	2.2*2	3/4	15	20--30	300017002300
WS1530	350*2	1500*3000	3.0*2	3/4	15*2	50--80	310020002500
2WS1530	350*2	1500*3000	3.7*2	3/4	15*2	50--100	310020002800
WS1840	350*2	1800*4000	3.7*2	3/4	15*2	100--130	420023002800
2WS1840	350*2	1800*4000	3*4	3/4	15*2	100--150	455023002800
WS2050	500*2	2000*5000	3.7*4	3/4或4/6	18.5*2	150--200	520025003100
2WS2060	500*2	2000*6000	3.7*4	2/3	22*2	200--260	650025003100

*Details may vary based on application
**Weight inclusive of motor & accessories.
Note:All the above technical details may vary at any time during engineering process & design development.
