Series Sand Washer
XSD

The transmission part of XSD Sand Washing Machine is separated from water and sand and the failure rate is much lower than other sand washing machines. Its novel sealing structure and reliable transmission device ensure the effect of cleaning and dewatering. It has the characteristics of reasonable structure large capacity and low power consumption. It is an ideal sand washing equipment in sand and stone industry.

WATCH VIDEO

TECHNICAL DATA

Model	XSD2610	XSD2816	XSD3016	XSD3620
Impeller of Diameter(mm)	2600	2800	3000	3600
Feeding Size(mm)	≤10	≤10	≤10	≤10
Capacity(t/h)	20~60	30~60	70~120	80~160
Model of Motor	Y160L-8	Y180L-8	Y200L-8	Y225S-8
Power(kW)	7.5	11	15	18.5
Water Requirement(t/h)	10-30	10-40	10-60	20-110
Weight(t)	2.7	5.5	6.1	9.7
Dimension(L×W×H)(mm)	3254×2060×2622	3810×2820×2883	3810×2820×3083	4624×3443×3680

*Details may vary based on application
**Weight inclusive of motor & accessories.
Note:All the above technical details may vary at any time during engineering process & design development.
